This blog would let you try on controlling 2 Servo Motors thru a Thumb Joystick, programmed with gizDuino UNO-SE


Materials Needed:


1. gizDuino UNO -SE


2. Thumb Joystick (commonly found on PS2 controllers)


3. 2pcs - SG-90 Servo Motors


4. Pan Tilt accessories


5. Jumper wires


Wiring Set-up:



1. Connect Thumb Joystick's VCC and GND to gizDuino UNO-SE's +5V and GND respectively.


2. Then connect the "Vertical" input to Analog Pin 5 (A5), "Horizontal" Input to Analog Pin 4 (A4) and, "Select" input to Analog Pin 3 (A3).


3. Connect Servo Motor A and B's VCC and GND to gizDuino UNO-SE's +5V and GND respectively.


4. Then, connect Servo Motor A input pin to Digital Pin 5 (D5) and Servo Motor B to Digital Pin 6 (D6).


5. Plug-in your gizDuino UNO-SE to your PC and open Arduino IDE and let us start uploading the sample program and try!



Codes:



Documented by: King Johnnel Olgado
