EWM-654 Mp3 Module

EWM-654 Mp3 Module
EWM-654 Mp3 Module
Based on 0 reviews. - Write a review
₱450.00
  • Stock: In Stock
  • Product Code: 580012020
  • Weight: 0.00g
  • Product ID: 8
Add to Cart
Buy Now
Add to Wish List Compare this Product

The player provides a line-out signal, suitable for connecting to the auxiliary input of an amplifier or head-end unit. A high-resolution 24-bit DAC and dedicated decoder DSP produce a quality sound even at low bitrates.



Features :
- Supports outer inlet signal shift USB/SD card,AUX state accept outer amplifier signal input.
- FM Radio available,multi-color LED display
- MP3 decoder slot on board.
- USB,SD,MMC card supported，8G max supported.
- NEXT,PREV,VOL+,VOL-,EQ(4 options),PLAY/PAUSE Supported.
- FAT12,FAT16 files system supported.
- MP1 Layer3、MP2 Layer3、MP3 Layer3,WMA format files supported.
- Supports 32~320kbp rates mp3 files.
- Remote controllable, effective range 10 m.
- Single 5V/12V DC power supply input.
- Low power consumption 25 mA typical (with LED display).
- Your music file can be stored anywhere of the flash memory which can be sorts according some smart rules.


Downloads :
Hardware Manual
Download
BlogLink
Audio Interfacing Application NotesDownload
