Dinkle PCB Barrier Screw Terminal Block 5-way 40A 13mm pitch DT-7

Tags: connector

Description
Reviews

Genuine Dinkle DT-7 Series Barrier Terminal Block.

Base Model: DT-7
Rating: 40A 600V
No of Pole/Pins: 5 way 5 pins
Pin Spacing (Pitch): 13.0mm
Wire Size: AWG18-AWG8
Recommended PCB Hole Size: d2.7mm

Insulation Material: PBT
Conductor Material: Copper Alloy
Safety Approvals: UL

Prices and stock availability subject to change without prior notice. If you want this product but it indicates it is not in stock, chat us or simply add it to your cart anyway. Our staff will contact you to inform if we can/cannot provide the item in your order.
