Chemi-con 120uF 10V 125C Conductive Polymer Solid Capacitor NPCAP PXH Series

Tags: capacitor , tantalum capacitor , smd tantalum , tantalum

Description
Reviews

Nippon Chemi-con Conductive Polymer Aluminum Solid Capacitors SMD.

Extended Temperature.

Super low ESR, impedance and high heat resistance have been obtained by using conductive polymer as electrolyte.

Manufacturer Part No: APXH100ARA121MH70G
Capacitance: 120uF +/-20%
Working Voltage: 10VDC
Category Temperature Range: -55C to +125C
Dissipation Factor: 0.12 @120Hz
Ripple Current: 2800mA @ 100kHz +105C
Impedance: 0.035 ohms
Dimensions: d6.3 x 7.7mm

Markings may vary from what is shown in the image.

Prices and stock availability subject to change without prior notice. If you want this product but it indicates it is not in stock, chat us or simply add it to your cart anyway. Our staff will contact you to inform if we can/cannot provide the item in your order.
