HLK-WIFI-M03 UART to WiFi Module

Based on 0 reviews. - Write a review

₱1,445.00

Stock: In Stock
Product Code: 580011987
Weight: 0.00g
Product ID: 508

Add to Cart

Buy Now

Add to Wish List Compare this Product

Description
Reviews

UART-WiFi is an embedded module based on the UART serial, in accordance with the WiFi wireless WLAN standards, IEEE802.11 protocol stack and TCP / IP protocol stack. It enables the data conversion between the user serial and the wireless network module through the UART - WiFi module. Traditional serial devices can easily access to the wireless network.

Specifications :

Power Input	3.3±0.3V DC
Frequency Range	2.412 ~ 2.484 GHz
Wireless Standard	IEEE802.11b/g
Receiver Sensitivity	802.11b: -86 dBm @ 11Mbps ( Typical ) 802.11b: -71 dBm @ 54Mbps ( Typical )
Transfer Rate	802.11b: 1, 2, 5, 5, 11 Mbps 802.11b: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation	DSSS, OFDM, DBPSK, DQPSK, CCK, QAM16/64
Output Power	802.11b: 18±2 dBm ( Typical ) 802.11b: 15±1 dBm ( Typical )
Serial Type	UART
Serial Baudrate	1200 ~ 115200 bps
Network Type	Infra / Adhoc

Specifications :

Technical Manual	Download
Software	Download

Prices and stock availability subject to change without prior notice. If you want this product but it indicates it is not in stock, chat us or simply add it to your cart anyway. Our staff will contact you to inform if we can/cannot provide the item in your order.
