TB6612 2 CH General Purpose Motor Driver 1A

Compact dual H-bridge motor driver capable of controlling two DC motors or one stepper motor. Delivering up to 1.2A continuous current per channel, it features built-in thermal protection, high efficiency, and low power consumption—making it a superior, energy-efficient alternative to traditional L298N drivers for Arduino, Raspberry Pi, and robotics projects.



Key Features & Overview:
-Dual Channel Control: Independently drives up to two DC motors or one 4-wire bipolar stepper motor.
-High Efficiency: MOSFET-based H-bridge design offers minimal voltage drop and higher power efficiency compared to L298N drivers.
-Output Current: 1.2A continuous (3.2A peak) per channel.
-Operating Voltage: Motor supply voltage 2.5V to 13.5V; Logic supply voltage 2.7V to 5.5V.
Built-in Protection: Includes thermal shutdown and low-voltage detecting circuits.

Package Contents: Includes 1x TB6612FNG module and 2x male pin headers (un-soldered).
